Intel Desktop Board DH67GD Product Guide
10
Table 1. Feature Summary (continued)
Peripheral
Interfaces
USB Support:
• Two USB 3.0 ports implemented with stacked back panel
connectors
• Fourteen USB 2.0 ports:
― Six ports implemented with stacked back panel connectors
― Eight front panel ports implemented with four dual-port
internal headers
Serial ATA Support:
• Two Serial ATA (SATA) 6.0 Gb/s ports
• Two Serial ATA (SATA) 3.0 Gb/s ports
• Two external SATA (eSATA) 3.0 Gb/s ports (one on the board and
one on the back panel)
IEEE 1394a Support:
• One back panel port
• One onboard header
Legacy I/O
Legacy I/O Controller (Nuvoton* W83677HG-I) that provides
Consumer Infrared (CIR) support
LAN Support Intel
®
82579V Gigabit (10/100/1000 Mb/s) Ethernet LAN controller
including an RJ-45 back panel connector with integrated status LEDs
BIOS
• Intel
®
BIOS resident in an Serial Peripheral Interface (SPI) Flash
device
• Support for Advanced Configuration and Power Interface (ACPI),
Plug and Play, and System Management BIOS (SMBIOS)
• Unified Extensible Firmware Interface (UEFI) to support hard disk
drives larger than 2 TB
• BIOS support for Hyper Boot
Instantly Available
PC Technology
• Support for PCI Local Bus Specification Revision 2.3
• Support for PCI Express Base Specification Revision 2.0
• Suspend to RAM support
• Wake on PCI Express, LAN, front panel, CIR, and USB ports
Hardware
Management
Nuvoton W83677HG-I based subsystem, including:
• Voltage sense to detect out of range power supply voltages
• Thermal sense to detect out of range thermal values
• Three fan headers using Pulse Width Modulation (PWM) control
• 4-pin headers for processor and chassis fans
• 4-wire and 3-wire (linear) fan speed control support for the
chassis fans
• Support for Platform Environmental Control Interface (PECI)
