Intel Desktop Board DH67GD Product Guide
18
Audio Subsystem
The board supports Intel High Definition Audio through a Realtek ALC892 audio codec
as well as through the HDMI interface.
The Realtek ALC892-based audio subsystem provides the following features:
• Advanced jack sense for the back panel audio connectors that enables the audio
codec to recognize the device that is connected to an audio port
• Stereo input and output via back panel connectors
• Headphone and Mic in functions for front panel audio connectors
• 97 dB Signal-to-Noise ratio (SNR) playback (DAC) quality and 90 dB SNR recording
(ADC) quality
• Content protection for full-rate loss-less DVD Audio and Blu-ray Disc* audio
content playback (with selected versions of media player software)
The audio subsystem supports the following audio interfaces:
• 7.1 analog back panel audio connectors
• Optical S/PDIF-out back panel audio connector
• S/PDIF-out header with support for optical or coaxial S/PDIF output
• Front panel audio header with support for Intel HD Audio and AC ’97 Audio
Table 3 lists the supported functions of the front pa
nel (FP) and
back panel (BP) audio
jacks.
Table 3. Audio Jack Retasking Support
Audio
Jack
Micro-
phone
Head-
phones
Front
Speakers
Line In
Micro-
phone/
Side
Surround
Rear
Surround
Center/
Subwoofer
FP Green Default
FP Pink Default
BP Blue Default
BP Green Control
panel
Default
BP Pink Default
BP Black Default
BP Orange Default
