Intel DH67GD User Manual

Desktop Board Features
13
Table 2. Intel Desktop Board DH67GD Components
Label Description
A Conventional PCI bus connector
B PCI Express 2.0 x1 add-in card connector
C IEEE 1394a header
D PCI Express 2.0 x1 add-in card connector
E PCI Express 2.0 x16 add-in card connector
F Back panel connectors
G 12 V processor core voltage connector (2 x 2 pin)
H Rear chassis fan header
I Processor socket
J Processor fan header
K DDR3 DIMM 3 socket
L DDR3 DIMM 1 socket
M DDR3 DIMM 4 socket
N DDR3 DIMM 2 socket
O Front chassis fan header
P Chassis intrusion header
Q Front panel CIR receiver (input) header
R Back panel CIR emitter (output) header
S Main power connector (2 x 12 pin)
T Battery
U Speaker
V SATA connectors
W Front panel header
X Alternate front panel power LED header
Y BIOS configuration jumper block
Z Front panel USB 2.0 headers
AA Standby power indicator LED
BB S/PDIF header
CC Front panel audio header
