Intel Desktop Board DP43TF Product Guide
12
Table 2. Intel Desktop Board DP43TF Components
Label Description
A PCI bus connector 3
B S/PDIF header
C PCI bus connector 2
D PCI bus connector 1
E PCI Express 1.1 x1 connector 3
F Chassis intrusion header
G Front panel audio header
H PCI Express 1.1 x1 connector 2
I PCI Express 2.0 x16 connector
J PCI Express 1.1 x1 connector 1
K Back panel connectors
L Rear chassis fan header (3-pin)
M 12 V processor core voltage connector (2 x 2 pin)
N Processor fan header (4-pin)
O Processor socket
P DDR2 DIMM 0 sockets
Q DDR2 DIMM 1 sockets
R Main power connector (2 x 12 pin)
S Front chassis fan header (3-pin)
T BIOS configuration jumper block
U IDE connector
V Serial header
W Serial ATA connectors (6)
X Front panel header
Y Alternate front panel power LED header
AA IEEE 1394a header
BB HD audio link header
CC High-speed USB 2.0 headers (3)
DD Battery
EE Speaker
For more information about Intel Desktop Board DP43TF, go to
http://intel.com/design/motherbd
.
