Product Description
35
1.13.2.5 Wake from USB
USB bus activity wakes the computer from ACPI S3 states.
NOTE
Wake from USB requires the use of a USB peripheral that supports Wake from USB.
1.13.2.6 PME# Signal Wake-up Support
When the PME# signal on the PCI Conventional bus is asserted, the computer wakes
from an ACPI S3, S4, or S5 state (with Wake on PME enabled in the BIOS).
1.13.2.7 WAKE# Signal Wake-up Support
When the WAKE# signal on the PCI Express bus is asserted, the computer wakes from
an ACPI S3, S4, or S5 state.
1.13.2.8 Wake from Consumer IR
CIR activity wakes the computer from an ACPI S3, S4, or S5 state.
1.13.2.9 Wake from S5
When the RTC Date and Time is set in the BIOS, the computer will automatically wake
from an ACPI S5 state.
