Technical Reference
45
Table 20. Front Panel CIR Receiver (Input) Header
Pin Signal Name
1 Ground
2 LED
3 NC
4 Learn-in
5 5 V standby
6 VCC
7 Key (no pin)
8 CIR Input
2.2.2.2 Add-in Card Connectors
The board has the following add-in card connectors:
• PCI Express 2.0 x16: one PCI Express 2.0 x16 connector supporting simultaneous
transfer speeds up to 8 GB/s of peak bandwidth per direction and up to 16 GB/s
concurrent bandwidth.
• PCI Express 2.0 x1: two PCI Express 2.0 x1 connectors. The x1 interface supports
simultaneous transfer speeds up to 2.5 Gb/s of peak bandwidth per direction and
up to 5.0 Gb/s concurrent bandwidth.
• PCI Conventional (rev 2.3 compliant) bus: one PCI Conventional bus add-in card
connector.
Note the following considerations for the PCI Conventional bus connector:
• The PCI Conventional bus connector is bus master capable.
• SMBus signals are routed to the PCI Conventional bus connector. This enables PCI
Conventional bus add-in boards with SMBus support to access sensor data on the
desktop board. The specific SMBus signals are as follows:
The SMBus clock line is connected to pin A40.
The SMBus data line is connected to pin A41.
