Intel Desktop Board DP67DE Technical Product Specification
42
Table 10 lists the component-side connectors and headers identified in Figure 10.
Table 10. Component-side Connectors and Headers Shown in Figure 10
Item/callout
from Figure 10 Description
A PCI Conventional bus add-in card connector
B Front panel audio header
C PCI Express x1 bus add-in card connector
D PCI Express x1 bus add-in card connector
E PCI Express x16 bus add-in card connector
F Processor core power connector (2 x 2)
G Rear chassis fan header
H Processor fan header
I Front chassis fan header
J Chassis intrusion header
K LPC Debug header
L Consumer IR emitter (output) header
M Consumer IR receiver (input) header
N Main power connector (2 X 12)
O SATA connectors
P Front panel header
Q Alternate front panel power LED header
R Front panel USB 2.0 header
S Front panel USB 2.0 header
T Front panel USB 2.0 header
U Front panel USB 2.0 header
V S/PDIF out header
W Front panel audio header
