Intel DP67DE - SATA Connectors; S;PDIF Header; Chassis Intrusion Header; Processor, Front, and Rear Chassis (4-Pin) Fan Headers

Intel Desktop Board DP67DE Technical Product Specification
44
Table 15. SATA Connectors
Pin Signal Name
1 Ground
2 TXP
3 TXN
4 Ground
5 RXN
6 RXP
7 Ground
Table 16. S/PDIF Header
Pin Signal Name
1 Ground
2 S/PDIF out
3 Key (no pin)
4 +5 V DC
Table 17. Chassis Intrusion Header
Pin Signal Name
1 Intruder#
2 Ground
Table 18. Processor, Front, and Rear Chassis
(4-Pin) Fan Headers
Pin Signal Name
1 Ground
(Note)
2 +12 V
3 FAN_TACH
4 FAN_CONTROL
Note: These fan headers use Pulse Width Modulation control for fan speed.
Table 19. Back Panel CIR Emitter (Output) Header
Pin Signal Name
1 Emitter out 1
2 Emitter out 2
3 Ground
4 Key (no pin)
5 Jack detect 1
6 Jack detect 2
