Intel Desktop Board DQ965CO Product Guide
14
The desktop board supports the dual or single channel memory configurations defined
below.
• Four 240-pin Double Data Rate 2 (DDR2) SDRAM Dual Inline Memory Module
(DIMM) connectors with gold-plated contacts.
• Support for:
― Unbuffered, non-registered single or double-sided DIMMs
― Non-ECC DDR2
― DIMM Type and Timings listed below:
Type Timing
DDR2-800 5-5-5 or 6-6-6 only
DDR2-667 5-5-5 only
DDR2-533 4-4-4 only
― Serial Presence Detect (SPD) memory only
― Memory configurations listed below:
• Up to 2.0 GB utilizing 256 Mb technology
• Up to 4.0 GB utilizing 512 Mb or 1 Gb technology
• Up to 8.0 GB utilizing 1 Gb technology
NOTE
1 Gb memory technology is not supported on DDR2-800 DIMMs.
Intel recommends using memory from the tested memory lists, available at:
http://www.cmtlabs.com/mbsearch.asp
or
http://www.intel.com/products/motherboard/index.htm?iid=HMPAGE+Header_2_Pro
duct_MB
Related Links:
Go to the following links or pages for more information about:
• SDRAM specifications,
http://www.intel.com/technology/memory/
• Installing memory, page
38 in Chapter 2
