Intel Desktop Board DX58SO2 Product Guide
16
Intel
®
X58 Express Chipset
The Intel X58 Express Chipset consists of the following devices:
• Intel X58 Express Chipset I/O Hub (IOH)
• Intel 82801IJR I/O Controller Hub (ICH10R)
The IOH provides interfaces to the processor and the PCI Express bus. ICH10R is the
centralized controller for the board’s I/O paths.
Go to the following link for more information about the Intel X58 Express Chipset:
http://developer.intel.com/products/chipsets/index.htm
Audio Subsystem
The onboard audio subsystem consists of the following components:
• Intel
®
ICH10R I/O controller hub
• RealTek ALC892 codec
The subsystem has the following headers and connectors:
• Back panel audio connectors, including an S/PDIF optical port
• High Definition (HD) Audio front panel header that provides mic in and line out
signals for front panel audio connectors
• S/PDIF header
The audio subsystem supports the following features:
• Dolby* Home Theater
• A signal-to-noise (S/N) ratio of 95 dB
• Independent multi-streaming 8-channel (7.1) audio (using the back panel audio
connectors) and 2-channel audio (using the Intel High Definition Audio front panel
header)
Go to the following link or pages for more information about:
• The location of the onboard audio headers, Figure 23 on page 48
• The si
gnal
names for the Intel High Definition Audio front panel header, page 49
• The back
panel audio connectors, Figure 24 on page 53
