Installing and Replacing Desktop Board Components
35
Installing and Removing a Processor
Instructions on how to install the processor on the Desktop Board are given below.
Installing a Processor
CAUTION
Before installing or removing a processor, make sure the AC power has been removed
by unplugging the power cord from the computer; the standby power LED should not
be lit (see Figure 4 on page 24). Failure to do so could damage the processor and the
board.
T
o in
stall a processor, follow these instructions:
1. Observe the precautions in "Before You Begin" on page 31.
2. Open the so
cket lever by push
ing the lever down and away from the socket
(Figure 9, A and B).
Figure 9. Unlatch the Socket Lever
