Installing and Replacing Desktop Board Components
63
Installing the WiFi/Bluetooth* Module in a
Desktop Chassis
NOTE
The WiFi/Bluetooth*module is supplemental hardware that is included with certain
Desktop Boards. Additional WiFi/Bluetooth modules can be ordered online from
http://click.intel.com/Desktop_system_parts-0-C97.aspx
.
Installing the WiFi/Bluetooth module that is shipped with Intel Desktop Board
DX58SO2 in your desktop system allows you to connect to wireless networks and
Bluetooth peripherals.
The recommended installation procedure for a typical desktop chassis is as follows:
1. Observe the precautions in "Before You Begin" on page 31.
2. Make s
u
re that the system is turned off and disconnected from its power source.
3. Remove the plastic cover from an empty 5-1/4 inch drive bay in the chassis bezel
(Figure 29, A).
4. Remove the
metal filler
plate from the internal drive bay (Figure 29, B).
5. Remove the paper backing covering the
adhesive on the back of the WiFi/Bluetooth
Module and attach the module to the back side of the plastic drive bay cover
(Figure 29, C).
6. C
o
nnect one end of the USB cable to the connector on the front of the module
(Figure 29, D).
7. Rein
st
all the plastic drive bay cover in the chassis bezel while routing the USB
cable into the chassis through the empty drive bay (Figure 29, E).
8. C
o
nnect the free end of the USB cable to an unused front panel USB header on the
Desktop Board (see Figure 23, G for locations) (Figure 29, F).
