Page #14 background imageLoading...
Page #14 background image
Intel Desktop Board DZ68ZV Technical Product Specification
14
Table 2. Components Shown in Figure 1
Label Description
A PCI Express x1 bus add-in card connector
B Conventional PCI bus add-in card connector
C PCI Express 2.0 x16 connector (x8 electrical; x16 compatible)
D Front panel audio header
E Conventional PCI bus add-in card connector
F PCI Express x1 bus add-in card connector
G PCI Express 2.0 x16 bus add-in card connector
H Rear chassis fan header
I PCI Express x1 bus add-in card connector
J Back panel connectors
K 12 V processor core voltage connector (2 x 4 pin)
L LGA1155 processor socket
M Processor fan header
N DIMM 3 (Channel A DIMM 0)
O DIMM 1 (Channel A DIMM 1)
P DIMM 4 (Channel B DIMM 0)
Q DIMM 2 (Channel B DIMM 1)
R Alternate front panel power LED header
S Main power connector (2 x 12 pin)
T POST code LED display
U Onboard power button
V Onboard reset button
W Speaker
X Front chassis fan header
Y Battery
Z Intel Z68 Express Chipset
AA SATA connectors (6)
BB Consumer IR transmitter (output) header
CC Consumer IR receiver (input) header
DD BIOS Setup configuration jumper block
EE Front panel USB 2.0 headers (3)
FF Chassis intrusion header
GG IEEE 1394a front panel header
HH Front panel header
II Diagnostic LEDs
JJ S/PDIF out header
KK Auxiliary fan header
