Intel Desktop Board DZ68ZV Technical Product Specification
22
NOTE
The SATA Drive Mode must be set to RAID in the BIOS Setup in order for your
system to use Intel Smart Response Technology. Once RAID is enabled, you can
install the operating system and the Intel Rapid Storage Technology driver. If
the operating system was already installed with the SATA Drive Mode set to
AHCI, you must reinstall the operating system with the SATA Drive Mode set to
RAID.
For more information on Intel Smart Response Technology refer to
http://download.intel.com/design/flash/nand/325554.pdf
or download the Intel Smart
Response Technology User Guide at
http://www.intel.com/support/motherboards/desktop/dz68db/sb/CS-
032499.htm?wapkw=(smart+response)
1.6.2 USB
The board supports up to 14 USB 2.0 ports and two USB 3.0 ports.
The Intel Z68 Express Chipset provides the USB controller for the 2.0 ports. The two
USB 3.0 ports are provided by the NEC* UPD720200 controller. The port arrangement
is as follows:
• Two USB 3.0 ports are implemented with stacked back panel connectors (blue)
• Eight USB 2.0 ports are implemented with stacked back panel connectors (black)
• Six USB 2.0 front panel ports implemented through four internal headers
All 16 USB ports are high-speed, full-speed, and low-speed capable. The USB 3.0 ports
are super-speed capable.
NOTES
Computer systems that have an unshielded cable attached to a USB port may not
meet FCC Class B requirements, even if no device is attached to the cable. Use a
shielded cable that meets the requirements for full-speed devices.
For information about Refer to
The location of the USB connectors on the back panel Figure 10, page 46
The location of the front panel USB headers Figure 11, page 47
