Intel Desktop Board DZ68ZV Product Guide
34
Installing and Removing the Desktop Board
CAUTION
Only qualified technical personnel should perform this procedure. Disconnect the
computer from its power source before performing the procedures described here.
Failure to disconnect the power before you open the computer can result in personal
injury or equipment damage.
Refer to your chassis manual for instructions on installing and removing the Desktop
Board.
Figure 8 shows the location of the mounti
ng screw holes for Intel Desktop Board
DZ68ZV.
Figure 8. Intel Desktop Board DZ68ZV Mounting Screw Hole Locations
