Intel EMB-H61A - Specifications

Industrial Motherboard
EMB-H61A
Chapter 1 General Information
1-3
1.2 Specifications
System
 Processor
Intel
®
2
nd
/3
rd
generation Core™ i5/i3
Processor, up to 35W
 System Memory
204-pin dual-channel DDR3
1333/1066 SODIMM x 2, Max. 16
GB
 Chipset
Intel
®
H61 (B3)
 I/O Chipset
Fintek F81866D
 Ethernet
Realtek 8111E for
10/100/1000Base-T, RJ-45 x 2
 BIOS
AMI BIOS, 64MB ROM
 Wake On LAN
Yes
 Watchdog Timer
System reset: 1~255 steps
programmable
 TPM
Optional
 H/W Status Monitoring
Monitoring System Temperature,
Voltage, and Cooling Fan status
 Expansion Interface
PCI-Express 2.0 [x4] x 1, Mini PCIe
x 1 (full size for mSATA support,
optional)
 Battery
Lithium battery
 Power Requirement
4-pin connector for DC12V input x 1;
CPU fan x 1, System fan with 4-pin
wafer x 1;
SATA power with 4-pin wafer x 1
 Power Compliance
Compliant with EuP/ErP
 Board Size
6.7”(L) x 6.7”(W) (170 mm x 170
mm)
