Intel EMB-H61A - 1000 Base-T Ethernet Connector with Dock USB 2.0 Connector (CON17;CON18); Digital I;O Connector (DIO)

Industrial Motherboard
EMB-H61A
Chapter 2 Quick Installation Guide 2 - 12
17
GND
18
GND
2.15 1000Base-T Ethernet Connector with Dock USB 2.0 Connector
(CON17/CON18)
Pin
Signal
Pin
Signal
1
+5V
2
USB2_DN2
3
USB2_DP2
4
GND
5
+5V
6
USB2_DN1
7
USB2_DP1
8
GND
9
LAN_CTR
10
LAN_MDI_DP0
11
LAN_MDI_DN0
12
LAN_MDI_DP1
13
LAN_MDI_DN1
14
LAN_MDI_DP2
15
LAN_MDI_DN2
16
LAN_MDI_DP3
17
LAN_MDI_DN3
18
GND
19
LAN_LED_ACT
20
LAN_LED_ACT#
21
LAN_LED_LINK100#
22
LAN_LED_LINK1000#
23
GND
24
GND
25
GND
26
GND
27
GND
28
GND
29
GND
30
GND
2.16 Digital I/O Connector (DIO)
Pin
Signal
Pin
Signal
1
DIO_I#1 (DIO_P#1)
2
DIO_I#2 (DIO_P#2)
3
DIO_I#3 (DIO_P#3)
4
DIO_I#4 (DIO_P#4)
5
DIO_O#1 (DIO_P#5)
6
DIO_O#2 (DIO_P#6)
