Intel EMB-H61A - BIOS Programmable Connector (SPI); Internal USB 2.0 Connector (USB1)

Industrial Motherboard
EMB-H61A
Chapter 2 Quick Installation Guide 2 - 16
4
GND
2.23 BIOS Programmable Connector (SPI)
4BPin
25BSignal
Pin
5BSignal
1
+V3.3SPI
2
GND
3
SPI_CS#
4
SPI_CLK
5
SPI_MISO
6
SPI_MOSI
7
(NC)
8
(NC)
2.24 Internal USB 2.0 Connector (USB1)
Pin
Signal
Pin
Signal
1
+5V
2
GND
3
USB2_DN1
4
GND
5
USB2_DP1
6
USB2_DP2
7
GND
8
USB2_DN2
9
GND
10
+5V
