Intel EMB-H61A - List of Mating Connectors and Cables

Industrial Motherboard
EMB-H61A
Appendix C Mating Connector C - 2
C.1 List of Mating Connectors and Cables
The table notes mating connectors and available cables.
Connector
Label
Function
Mating Connector
Vendor
Model no
ATX12V
ATX 4P Power Connector
PINREX
740-41-04TWC0
AUDIO1
Audio jack Connector
FOXCONN
JA33331-2119-4F
BATTERY1
RTC - Coin Battery Holder
LOTES
KB7566BP5L
COM2
Int. COM2 RS-232 Serial
Port Connector
PINREX
52M-90-10GBE0
COM3
Int. COM2 RS-232 Serial
Port Connector
PINREX
52M-90-10GBE0
COM4
Int. COM2 RS-232 Serial
Port Connector
PINREX
52M-90-10GBE0
COM5
Int. COM2 RS-232 Serial
Port Connector
PINREX
52M-90-10GBE0
COM6
Int. COM2 RS-232 Serial
Port Connector
PINREX
52M-90-10GBE0
CON14
D-Sub9_Series Port
Connector with DVI-D
Connector
FOXCONN
QH11121-DBCH-4F
CON17
1000 Base-T Ethernet
Connector with Dock USB
2.0 Connector
FOXCONN
JFM38U1M-21GS-4F
CON18
1000 Base-T Ethernet
Connector with Dock USB
2.0 Connector
FOXCONN
JFM38U1M-21GS-4F
CON19
PS/2 Keyboard/Mouse
Connector with Dock USB
2.0 Connector
FOXCONN
UB11121-HSDB-4F
CON2
D-Sub15_VGA Connector
with HDMI Connector
FOXCONN
QJ11197-VES1-4F
CON3
mini PCI-E Slot
LOTES
AAA-PCI-073-K02
