Intel EMB-H61A - Page 82

Industrial Motherboard
EMB-H61A
Appendix C Mating Connector C - 3
CON4
Compact Flash Slot
PROCONN
CFH050-A0-53G6
DEBUG
Debug Connector
ACES
87212-12G0
DIMM_A1
DIMM1 Slot
FOXCONN
ATNA291-AED-4F
DIMM_B1
DIMM2 Slot
FOXCONN
ATNA291-AED-4F
DIO
Digital I/O Connector
PINREX
52S-90-10GB00
F_PANEL
Front Panel Connector
PINREX
210-92-05GB02
INV
Inverter Connector
PINREX
721-81-05TW00
LGA1
CPU Socket - LGA-1155P
LOTES
ACA-ZIF-096-P07
LVDS
LVDS Panel Signal
Connector
PINREX
712-76-30GWR8
PCIEX4
PCI Express x4 Slot
LOTES
AAA-PCI-022-K15
PWR1
SATA Power Connector
HR
A2540WV-4P
S_FAN1
System FAN Connector
PINREX
744-81-04TG20
S_FAN2
System FAN Connector
PINREX
744-81-04TG20
SATA1
SATA II Connector
PINREX
770-83-07SV29
SATA2
SATA II Connector
PINREX
770-83-07SV29
SIM1
SIM Card Socket
HAMBURG
ICA-509
SPI
BIOS Programmable
Connector
PINREX
232-92-04GBEM
USB1
Int. USB 2.0 Connector
PINREX
222-97-05GBE1
