Chapter 3 AMI BIOS Setup 3-9
Options summary :
DIO_P# 1-4
Input
Optimal Default, Failsafe
Default
Output
Set GPIO as Input or Output
DIO_P# 5-8
Input
Output
Optimal Default, Failsafe
Default
Set GPIO as Input or Output
DIO_P# 1-8
Direction
Low
High
Optimal Default, Failsafe
Default
Set GPIO Output as Hi or Low.
