Industrial Motherboard
EMB-H61A
Chapter 3 AMI BIOS Setup 3-15
Options summary :
F81866 ERP Function
Disabled
Default
Enabled
Enable or Disable ERP function.
Serial Port
Disabled
Enabled
Default
Allows BIOS to En/Disable correspond serial port.
Device Mode
RS232
Default
RS422
RS485
Select working model.
Change Settings
(Serial Port 1)
Auto
Default
IO=3F8h; IRQ=4;
IO=3F8h; IRQ=3,4;
IO=2F8h; IRQ=3,4;
IO=3E8h;
IRQ=10,11;
IO=2E8h;
IRQ=10,11
Allows BIOS to Select Serial Port resource.
Change Settings
(Serial Port 2)
Auto
Default
IO=2F8h; IRQ=3;
IO=3F8h; IRQ=3,4;
IO=2F8h; IRQ=3,4;
