Industrial Motherboard
EMB-H61A
Chapter 3 AMI BIOS Setup 3-19
Options summary :
SYS/CPU Smart Fan
Control
Auto by RPM
Default
Auto by Duty-Cycle
Manual by RPM
Manual by
Duty-Cycle
Select CPU Smart FAN mode
Auto by RPM: Automatically controlling the fan to maintain target
Fan Speed.
Auto by Duty-Cycle: Automatically controlling the fan to maintain
target temperature.
Manual by RPM: Manually controlling the fan with a given Fan
Speed.
Manual by Duty-Cycle: Manually controlling the fan with a given
control PWM.
Target Temp. Sensor
CPU Temperature
Default
PCH Temperature
