1 Desktop Board Features
This chapter briefly describes the features of Intel
®
Desktop Board DH61DL. Table 1
summarizes the major features of the Desktop Board.
Table 1. Feature Summary
Form Factor
Mini-ITX (170.18 millimeters [6.7 inches] x 170.18 millimeters
[6.7 inches])
Processor Support
• Intel
®
Core™ i7, Intel
®
Core™ i5, and Intel
®
Core™ i3 processors in
an LGA1155 package:
― Integrated graphics processing (processors with Intel
®
Graphics
Technology)
― Integrated memory controller
Chipset Intel
®
H61 Express Chipset consisting of the Intel
®
H61 Express
Platform Controller Hub (PCH)
Memory Support
• Two 240-pin DDR3 SDRAM Dual Inline Memory Module (DIMM)
sockets
• Support for DDR3 1333 MHz and DDR3 1066 MHz DIMMs
• Support for 1 Gb, 2 Gb, and 4 Gb memory technology
• Support for up to 8 GB of system memory with two DIMMs using
4 Gb memory technology
• Support for non-ECC memory
Graphics Support
• Integrated graphics support for processors with Intel Graphics
Technology:
― VGA
― DVI-D
• Discrete graphics support for PCI Express* 2.0 x1 add-in graphics
cards
Audio Intel
®
High Definition Audio (Intel
®
HD Audio):
• Realtek* ALC892 audio codec
• Front panel audio header (Intel HD Audio and AC ’97 Audio support)
• Mono speaker header
• S/PDIF audio header
Expansion
Capabilities
• One PCI Express 2.0 x1 add-in card connector
• One PCI Express Mini Card connector supporting Half-Mini and Full-
Mini Cards
continued
