3
1-2 Specification
Spec Description
Design
z Micro ATX form factor 4 layers PCB size: 24.5*18cm
Chipset
z Intel G41 Memory Controller Hub (MCH) Chipset
z Intel 82801GB I/O Controller Hub (ICH7) Chipset
CPU Socket
(LGA775 )
z Supports the innovative 65nm and 90nm Intel® Pentium® Dual Core
Processor
，
Intel® Core 2 Quad, Intel® Core 2 Duo® (Code Name:
Conroe) Processor with Intel® Hyper-Threading Technology and
fully supports the future 45nm processors. Suggest the power of the
CPU should below 65w
z Support FSB Frequency 1333 / 1066 / 800MHz
Memory Socket
z 240-pin DDR2 RAM module socket x 2 for MI5-G41SGMD2-LF
z MI5-G41SGMD2-LF supports dual-channel DDR2 667 /DDR2
800MHz RAM Module expandable to 8GB.
z 240-pin DDR3 RAM module socket x 2 for MI5-G41SGMD3-LF
z MI5-G41SGMD3-LF supports dual-channel DDR3 800
/DDR31066MHz RAM Module expandable to 8GB.
Expansion Slots
z PCI-Express x16 slot 1pcs.
z PCI-Express x1 slot 1pcs
z 32-bit PCI slot 2pcs
Integrate IDE and
Serial ATA2
z One PCI IDE controller that supports PCI Bus Mastering, ATA
PIO/DMA and the ULTRA DMA 33/66/100 functions that deliver the
data transfer rate up to 100 MB/s; four Serial ATA2 ports each
provides 3.0 Gb /sec data transfer rate.
Integrated VGA
z Integrated Graphic Media Accelerator 4500
LAN
z Integrated PCI-E 10/100 LAN chip
z Support Fast Ethernet LAN function of providing 10Mb / 100Mb
data transfer rate
HD Audio
z Realtek ALC662 Azalia 6-channel Audio Codec integrated
z Audio driver and utility included
BIOS
z AMI 8MB DIP Flash ROM
Multi I/O
z PS/2 keyboard and PS/2 mouse connectors
z Floppy disk drive connector x1
z Parallel header x1 / Serial port x1
z D-Sub 15-pin VGA Conn.
z USB 2.0 connector x 4, headers x2
z HDMI-SPDIF header x1
z SATA Connector x4
z RJ45 LAN connector x1
z Audio connector x1 (Line-in, Line-out, MIC)
To Next Page
