2
will automatically increase the fan speed when CPU operating loading is high, after
the CPU is in normal operating condition, the system will low down the fan speed for
the silent operating environment. The system can provide the much longer life cycle
for both CPU and the system fans for game use and business requirements.
Notice!
CPU Smart Fan is only optional for later version boards. To mask sure if
your board support this function please check BIOS settings.
1-2 Specification
Spec Description
Design z
U-ATX PCB size: 17.5 cm x 23.0 cm
Chipset z
Intel H61 Express Chipset
CPU Socket
z
supports the innovative Intel LGA 1155 socket Intel
®
Core™ i7, Core™ i5, Core™ i3 Processor
Memory Slot
z
DDRIII module slot x 2
z
Support 2pcs DDRIII 800/DDRIII 1066/DDRIII 1333
memory modules expandable to 8 GB
z
Support dual channel function
Expansion Slots
z
1pcs PCI-Express 2.0 x16 by16 lane slot
z
1pcs PCI-Express 2.0 x1 slot
Serial ATA2
z
The Intel H61chipset supports four internal SATA ports for
four SATA devices providing 3.0 Gb/sec data transfer rate
LAN chip
z
Integrated megabit PCI-E LAN chip that supports Fast
Ethernet LAN function of providing 10/100 Mbps data
transfer rate
HD Audio Chip
z
6-CHHD Audio Codec integrated
z
Audio driver and utility included
BIOS z
AMI 32MB DIP Flash ROM
Multi I/O
z
PS/2 mouse connector x1
z
PS/2 keyboard connector x 1
z
VGA connector x1
z
DVI connector x1
z
HDMI connectorx1 (Optional for I61M2 series only)
z
USB 2.0 port x4 and header x2
z
RJ-45 LAN connector x1
z
Audio connector x1 (6-CH Audio)
z
Front panel audio Header x1
z
HDMI-SPDIF header x1
z
Front panel header x1
z
PWELED header x1
z
Speaker header x1
Item Checklist
z
Intel H61 Chipset based motherboard
z
DVD for motherboard utilities
z
User’s Manual
z
SATA Cable
z
I/O back panel shield
