NVM Information Guide—ICH8/ICH9
14
Bit Name Default Description
8 Reserved 0b This bit is reserved and should be set to 0b.
7:6 PHYT 00b
This field indicates the PHY device type.
00b = 82566/82567 PHY - GLCI mode
01b = Reserved
10b = 82562V PHY - PCIe mode, LCI mode
11b = Reserved
This field is reflected in the PHYTYPE field in the Status register.
5D/UD Polarity 0b
This bit defines the polarity of the dock/undock indication as
defined.
0b = GBEDOCKB pin value of 0 = dock; 1 = undock.
1b = GBEDOCKB pin value of 0 = undock; 1 = dock.
This bit is loaded in the automatic read process to bit 14 of the
Device Control register.
4FRCSPD 0b
Force Speed
Default setting for the Force Speed bit in the Device Control
register (CTRL[11]). The hardware default value is 1b.
Note: This is a reserved bit for the 82566 and 82562V.
4:3 FD 0b
Duplex Setting
Default setting for duplex setting. Mapped to CTRL[0]. The
hardware default value is 1b.
Note: This is a reserved bit for the 82566 and 82562V.
2 CLK_CNT_1_16 1b
This bit is loaded to the CTRL_EXT.EnaKumCK16 bit and enables
the reduction of the internal JCLK to one-sixteenth of the external
NJCLK at the GLCI interface in Gigabit Ethernet mode.
0b = Reduction is disabled.
1b = Reduction is enabled.
1 CLK_CNT_1_4
1b
0b for
ICH9
This bit enables the automatic reduction of DMA frequency. It is
mapped to STATUS[31].
0b = Automatic reduction disabled.
1b = Automatic reduction enabled.
0
Dynamic Clock
Gating
1b
When set, this bit enables the dynamic clock gating of the DMA and
MAC units. This bit is loaded to the DynCK bit in the CTRL_EXT
register.
Note: This is a reserved bit for the 82566 and 82562V and
should be set to 1b.
Table 10. Shared Initialization Control (Word 13h)
