ICH8/ICH9—NVM Information Guide
Appendix A ICH8/ICH9 NVM Contents
This section contains the NVM contents for the ICH8/ICH9. All values are in
hexadecimal.
Table 23. LAN NVM Contents
Word Description
00:02h Ethernet Individual Address
03:04h Reserved
05h Image Version Information 1
06:07h Reserved
08:09h PBA Bytes
0Ah PCI Initialization Control Word
0Bh Subsystem ID
0Ch Subsystem Vendor ID
0Dh Device ID
0Eh Vendor ID
0Fh Device Revision ID (ICH9); Reserved (ICH8)
10h LAN Power Consumption
11:12h Reserved
13h Shared Initialization Control Word
14:16h Extended Configuration Words
17:18h LEDCTRL Words
19h Future Initialization Word (ICH8); Future Initialization Word 1 (ICH9)
1Ah Future Initialization Word 2 (ICH9)
1Bh:1Dh Reserved (ICH9)
1Eh 82567MM Device ID (ICH9)
1Fh 82567MC Device ID (ICH9)
20:21h Reserved (ICH9)
22h 82566DC Device ID (ICH9)
23h 82566DM Device ID (ICH9)
20:2Fh Reserved (ICH8)
24:2Fh Reserved (ICH9)
30:3Eh PXE Region
3Fh Software Checksum
