User Guide for NUC8i7BEHGA, NUC8i5BEHFA and NUC8i3BEHFA
4
Find compatible memory modules in the Intel® Product Compatibility Tool.
NUC8i7BEHGA
NUC8i5BEHFA
NUC8i3BEHFA
If you plan to install only one memory module, install it in the lower memory
socket.
To upgrade or add memory, follow these steps:
1. Observe the precautions in "Before You Begin" on page 2.
2. Turn off all peripheral devices connected to the computer. Turn off the computer and
disconnect the power cord.
3. Remove the computer’s bottom chassis cover.
Upgrade to different memory
a. Remove the pre-installed memory module
i. Gently spread the retaining clips at each end of the memory socket, which
causes the module to pop out of the socket (C).
ii. Holding the module by the edges, lift it away from the socket, and
store it in an anti-static package.
b. Install the new memory module
i. Align the small space at the bottom edge of the memory module with
the key in the socket.
ii. Insert the bottom edge of the module at a 45 degree angle into the
socket (A).
iii. When the module is inserted, push down on the outer edges of the
module until the retaining clips snap into place (B). Make sure the
clips are firmly in place (C).
Install an additional memory module
a. Align the small space at the bottom edge of the memory module with the key on the
socket.
b. Insert the bottom edge of the module at a 45 degree angle into the socket (A).
c. When the module is inserted, push down on the outer edges of the module
until the retaining clips snap into place (B). Make sure the clips are firmly in
To Next Page
