Intel PRO/1000 GT User Manual

Intel PROSet Installation
To install Intel PROSet on Microsoft* Windows Server* Nano Server:
1. Use the New-NanoServerImage cmdlet to add the PROSetNS.zip file from the
.\Disk\APPS\PROSETDX\NanoServer directory to your -CopyPath parameter.
2. Append the NanoSetup.ps1 file (located in the same directory) to your -SetupCompleteCommands
parameter.
For example:
New-NanoServerImage ...
-CopyPath "<PATH>\PROSetNS.zip", "<PATH>\NanoSetup.ps1" `
-SetupCompleteCommands "PowerShell ""C:\NanoSetup.ps1"""
See the link below for more information on deploying a Nano Server image and using the cmdlet:
https://msdn.microsoft.com/en-us/library/mt126167.aspx
Installing Intel PROSet
Intel PROSet for Windows Device Manager is an advanced configuration utility that incorporates additional
configuration and diagnostic features into the device manager.
NOTES:
l You must install Intel® PROSet for Windows Device Manager if you want to use Intel® ANS
teams or VLANs.
l Intel PROSet for Windows Device Manager is installed by default when you install the
device drivers. For information on usage, see Using Intel® PROSet for Windows Device
Manager.
Intel PROSet for Windows Device Manager is installed with the same process used to install drivers.
NOTES:
l You must have administrator rights to install or use Intel PROSet for Windows Device
Manager.
l Upgrading PROSet for Windows Device Manager may take a few minutes.
1. On the autorun, click Install Base Drivers and Software.
NOTE: You can also run setup64.exe from the files downloaded from Customer Support.
2. Proceed with the installation wizard until the Custom Setup page appears.
3. Select the features to install.
4. Follow the instructions to complete the installation.
If Intel PROSet for Windows Device Manager was installed without ANS support, you can install support by
clicking Install Base Drivers and Software on the autorun, or running setup64.exe, and then selecting the
Modify option when prompted. From the Intel® Network Connections window, select Advanced Network
Services then click Next to continue with the installation wizard.

Intel PRO/1000 GT Specifications

General

Interface	PCI
Data Rate	10/100/1000 Mbps
Connector	RJ-45
Network Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Form Factor	Plug-in card
Device Type	Network adapter
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet
Data Transfer Rate	1 Gbps
Bus Type	PCI
Full Duplex	Yes
Wake-on-LAN	Yes
Ports	1 x RJ45
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Operating Systems Supported	Windows, Linux, NetWare
Jumbo Frames	Yes, up to 9KB
