Intel PRO/1000 MT User Manual

Before beginning the configuration, update the adapter's UEFI FCoE Option ROM using the BootUtil tool and
the latest BootIMG.FLB file. Use the following command:
BOOTUTIL64E.EFI -up=efi+efcoe -nic=PORT -quiet
where PORT is the NIC adapter number (in the following example nic=1)
NOTE: The UEFI FCoE driver must be loaded before you perform the following steps.
Accessing the FCoEConfiguration Screen
Boot the system into its BIOSand proceed as follows:
1. Select the Advanced tab, then choose PCIConfiguration, then UEFIOption ROM Control, then
FCOEConfiguration.
2. The following screen is displayed:
Adding an FCoEAttempt
An FCoE Attempt is a configured instance of a target from which the system will attempt to boot over FCoE.

Intel PRO/1000 MT Specifications

General

Product Name	Intel PRO/1000 MT
Interface	PCI
Data Transfer Rate	1 Gbps
Connector	RJ-45
Compatibility	PC
Device Type	Network adapter
Form Factor	Plug-in card
Connectivity Technology	Wired
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet
Bus Type	PCI
Full Duplex Support	Yes
Jumbo Frames Support	Yes
Ports	1 x RJ-45
Features	Wake on LAN (WoL)
Compliant Standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Operating Systems Supported	Windows, Linux
