23
Launch LAN1/LAN2 PXE OpROM
Use this item to enable or disable boot option for legacy network devices.
Launch Storage OpROM
Use this item to enable or disable boot option for legacy mass storage devices with
option ROM.
ERP Function
Use this item to enable or disable ERP function for this board.
► PCI Subsystem Settings
Press [Enter] to enter and make settings for the following sub-items:
PCI ROM Priority
The optional settings: [Legacy ROM]; [EFI Compatible ROM].
PCI Latency Timer
Use this item to select value to be programmed into PCI Latency Timer Register.
The optional settings: 32/64/96/128/160/192/224/248 PCI Bus Clocks.
VGA Palette Snoop
Use this item to enable or disable VGA Palette Registers Snoop.
PERR# Generation
Use this item to enable or disable PCI Device to Generate PERR#.
SERR# Generation
Use this item to enable or disable PCI Device to Generate SERR#.
Relaxed Ordering
Use this item to enable or disable PCI express device relaxed ordering.
Extended Tag
If set as [Enabled] it will allow device to use 8-bit tag filed as a requester.
No Snoop
Use this item to enable or disable PCI Express device No Snoop option.
Maximum Payload
Use this item to set maximum payload of PCI Express device or allow system
BIOS to select the value.
Maximum Read Request
Use this item to set maximum read request size of PCI Express device or allow
system BIOS to select the value.
ASPM Support
The optional settings: [Disabled]; [Auto];[Force L0].
Extended Synch
If set as [Enabled] it will allow generation of extended synchronization patterns.
► ACPI Settings
ACPI Sleep State
Use this item to select the highest ACPI sleep state the system will enter when the
suspend button is pressed.
