Intel Q67 User Manual

1
Chapter 1
Introduction of the Motherboard
1-1 Specification
Spec Description
Design
z ATX form factor 4 layers;
Chipset
z Intel Q67 Express Chipset
CPU Socket
(LGA1155 )
z Intel
®
Socket LGA1155
* For detailed CPU support information please visit our website
Memory Slot
z DDRIII RAM module socket x 4 supporting four DDRIII
1333/1066MHz RAM Module expandable to 32 GB (Maximum)
z Support dual-channel function
Expansion Slots
z 4 pcs *32-bit PCI slot
z 1 pcs* PCI-Express 2.0 x16 slot
z 1 pcs* PCI-Express 2.0 x4 slot
z 1 pcs* PCI-Express 2.0 x1 slot
z 1 pcs*Mini-PCI-E x 1
Serial ATAⅠ
/Ⅱ
/
Ⅲ
z Support four serial ATA2 ports
z Support two serial ATA3 ports
Dual LAN Chip
z
Integrated Intel 82574L and 82579LM Gigabit Ethernet
LAN chip that supports Fast Ethernet LAN function of
providing 10Mb/100Mb/1000Mb Ethernet data transfer
rate
HD Audio Chip
z
VIA VT 1705CE 6-channel HD Audio Codec integrated
z Audio driver and utility included
BIOS
z 64MB SMT Flash ROM
Multi I/O
z PS/2 keyboard x1
z DVI Connector x1
z D-Sub 15-pin VGA Connector x1
z USB 2.0 connector x 6
z USB 2.0 headers x3
z RJ-45 LAN connector x2
z Serial port connector x1
z Audio connector x1
z Front panel header x1
z PER LED header x1
z Speaker header x1
z Front panel audio header x1
z CDIN header x1
z GPIO header x1
z TPM 1.2 header x1
z CIR header x1
z HDMI-SPDIF header x1
z Parallel header x1
z TX-RX COM1 header x 1
z COM port header x 9
