Intel Q67 User Manual

27
► Voltage Configuration
CPU Vcore 7-Shift
Use this item to adjust CPU voltage by 7 step value.
AXG Voltage
Use this item to adjust AGX voltage by 7 step value.
CPU VTT
Use this item to adjust CPU VTT voltage by 7 step value.
► WatchDog Configuration
WatchDog Timer Control
Use this item to enable or disable WatchDog Timer Control. When set as Enabled,
the following sub-items shall appear:
WatchDog Timer Value
User can set a value in the range of 4 to 255.
WatchDog Timer Unit
The optional settings are: [Second]; [Minute].
► Chipset Voltage Configuration
Use this item to choose the Voltage Parameters.
► Shutdown Temperature Configuration
Use this item to select system shutdown temperature.
► Serial Port Console Redirection
Console Redirection
The optional settings: [Enabled]; [Disabled].
► SmartFan Configuration
CPU FAN Smartfan Mode
Use this item to enable or disable Smartfan Mode.
3/4 Pin Fan Select
The optional settings are: [3 pin]/ [4 pin Fan].
SYSFAN1 Smart Mode
Use this item to enable or disable Smartfan Mode.
SYSFAN2 Smart Mode
Use this item to enable or disable Smartfan Mode.

Intel Q67 Specifications

General

Chipset	Intel Q67
Socket	LGA 1155
Memory Type	DDR3
Max Memory	32 GB
PCI Express Revision	2.0
Memory Slots	4
Memory Support	DDR3 1066/1333 MHz
USB Ports	14
SATA Ports	6
Integrated Graphics	Yes
RAID Support	RAID 0, 1, 5, 10
CPU Support	2nd Generation Intel Core i7/i5/i3 Processors
