29
South Bridge
Wake on Lan from S5
Use this item to enable or disable GbE control PME in S5.
Onboard Lan1 Device
Use this item to enable or disable the PCI Express Ports in the Chipset.
Restore AC Power Loss
Use this item to specify what state to go to when power is re-applied after a power
failure (G3 State). The optional settings are: [Power Off]; [Power On]; [Last State].
SLP_S4 Assertion Stretch Enable
The optional settings are: [Enabled]; [Disabled].
Deep SX
Deep SX Configuration
NOTE: Mobile platforms support Deep S4/S5 in DC only and Desktop platforms
support Deep S4/S5 in AC only.
Azalia HD Audio
The optional settings are: [Enabled]; [Disabled].
Azalia Internal HDMI Codec
Use this item to enable or disable internal HDMI codec for Azalia.
High Precision Timer
The optional settings are: [Enabled]; [Disabled].
USB Configuration
Press [Enter] to further setting USB port configuration.
ME subsystem
ME Subsystem
Use this item to enable or disable ME subsystem help.
ME Temporary Disable
The optional settings are: [Enabled]; [Disabled].
End of Post Message
The optional settings are: [Enabled]; [Disabled].
Execute MEBX
The optional settings are: [Enabled]; [Disabled].
MEBX Mode
The optional settings are:[normal]/[Hidden Ctrl+p]/Enter MEBX Setup.
