12
(9)CASE_OPEN(2-pin): Case Open Message Display Function Select
Pin 1-2 shorted: Case open display function enabled. Use needs to enter BIOS and
enable
‘
Case Open Detect
’
function. In this case if you case is removed, next time
when you restart your computer a message will be displayed onscreen to inform you
of this.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Intel Q77 and is the answer not in the manual?

Intel Q77 Specifications

General IconGeneral
ChipsetIntel Q77
Socket TypeLGA 1155
Memory TypeDDR3
Memory Slots4
Maximum Memory Supported32 GB
SATA 3Gb/s Ports4
SATA 6Gb/s Ports2
USB 2.0 Ports10
USB 3.0 Ports4
PCI Express Revision3.0
Integrated GraphicsIntel HD Graphics
PCIe 3.0 SupportYes
CPU SupportIntel Core i7/i5/i3, Pentium, Celeron (2nd and 3rd generation)
Memory SupportDDR3 1066/1333/1600 MHz
RAID SupportRAID 0, 1, 5, 10
