Intel Q77 User Manual

1
Chapter 1
Introduction of the Motherboard
1-1 Feature of Motherboard
z
Intel
®
Q77 express chipset
z
Supports 3
rd
and 2
nd
Generation Intel
®
Core™ i7, Core™ i5, Core™ i3 series
processor in LAG1155 Package
z
Support 2 * DDRIII SO-DIMM 1066-1333 MHz up to 16GB and dual channel
function
z
Integrated with Intel
®
82574L and Intel
®
82579LM Gigabit Ethernet LAN chip
z
Integrated ALC662 6-channel HD Audio Codec
z
Support USB 3.0 data transport demands.
z
Support PCI Express x16 and Mini-PCIE slot
z
Integrated with 24-bit dual channel LVDS
z
4* SATAII ports and 2* SATAIII ports
z
HDMI, DVI-D and VGA Video Outputs
z
Support CPU Smart FAN
z
Supports ACPI S3 Function
z
Compliance with EuP Standard
z
Support Watchdog Timer Technology

Intel Q77 Specifications

General

Chipset	Intel Q77
Socket Type	LGA 1155
Memory Type	DDR3
Memory Slots	4
Maximum Memory Supported	32 GB
SATA 3Gb/s Ports	4
SATA 6Gb/s Ports	2
USB 2.0 Ports	10
USB 3.0 Ports	4
PCI Express Revision	3.0
Integrated Graphics	Intel HD Graphics
PCIe 3.0 Support	Yes
CPU Support	Intel Core i7/i5/i3, Pentium, Celeron (2nd and 3rd generation)
Memory Support	DDR3 1066/1333/1600 MHz
RAID Support	RAID 0, 1, 5, 10
TDP	Not Applicable
