Intel® RAID Expander Card RES2SV240 Hardware User’s Guide 11
3 Intel
®
RAID Expander Card
RES2SV240 Characteristics
Figure 5. Card Layout
AF003493
J1
J2
J3
J4
J5
J6
J7
J8
J9
J10
