Intel® RAID Expander Card RES2SV240 Hardware User’s Guide 21
Figure 10. SFF8087 (with SGPIO) Connector Cable
Technical Specifications
Table 5. Technical Specifications
A15 GND P3_7 GND
A16 SAS_RX_C_DP<0> P3_6 SAS_TX_C_DP<3>
A17 SAS_RX_C_DN<0> P3_5 SAS_TX_C_DN<3>
A18 GND P3_4 GND
B16 SAS_TX_C_DP<0> P3_2 SAS_RX_C_DP<3>
B17 SAS_TX_C_DN<0> P3_3 SAS_RX_C_DN<3>
B18 GND P3_1 GND
Expander Connector Pin-Out Bac
kplane C
onnector Pin-Out
Pin No Signal Pin No Signal
Specification Intel
®
RAID Expander Card RES2SV240
Processor LSI* LSISAS2x24 24-Port Serial Attached SCSI/SA
TA
Expander chip
