20 Intel® RAID Expander Card RES2SV240 Hardware User’s Guide
Table 4. SFF8087 (with SGPIO) Connector Pin-out
Expander Connector Pin-Out Backplane Connector Pin-Out
Pin No Signal Pin No Signal
A1 GND P0_7 GND
A2 SAS_RX_C_DP<3> P0_6 SAS_TX_C_DP<0>
A3 SAS_RX_C_DN<3> P0_5 SAS_TX_C_DN<0>
B1 GND P0_4 GND
B2 SAS_TX_C_DP<3> P0_2 SAS_RX_C_DP<0>
B3 SAS_TX_C_DN<3> P0_3 SAS_RX_C_DN<0>
B4 GND P0_1 GND
A4 GND P1_7 GND
A5 SAS_RX_C_DP<2> P1_6 SAS_TX_C_DP<1>
A6 SAS_RX_C_DN<2> P1_5 SAS_TX_C_DN<1>
A7 GND P1_4 GND
B5 SAS_TX_C_DP<2> P1_2 SAS_RX_C_DP<1>
B6 SAS_TX_C_DN<2> P1_3 SAS_RX_C_DN<1>
B7 GND P1_1 GND
B8 SAS_A_SB0 1 SGPIO_SCLK
B9 SAS_A_SB1 2 SGPIO_SLOAD
B10 GND 4 SGPIO_GND
A9 GND
A10 SAS_A_SB4 3 SGPIO_SDATAOUT0
A11 SAS_A_SB5
A8 SAS_A_SB_BP_TYPE
B11 SAS_A_SB_CTRL_TYPE
A12 GND P2_7 GND
A13 SAS_RX_C_DP<1> P2_6 SAS_TX_C_DP<2>
A14 SAS_RX_C_DN<1> P2_5 SAS_TX_C_DN<2>
B12 GND P2_4 GND
B13 SAS_TX_C_DP<1> P2_2 SAS_RX_C_DP<2>
B14 SAS_TX_C_DN<1> P2_3 SAS_RX_C_DN<2>
B15 GND P2_1 GND
