System Event Log Troubleshooting Guide for EPSD Platforms Based on Intel
®
Xeon
®
Processor E5 4600/2600/2400/1600/1400 Product Families
PCI Express* and Legacy PCI Subsystem
Revision 1.1 Intel order number G90620-002 85
Table 69: PCI Express* Correctable Error Sensor Typical Characteristics
Byte
Field
Description
8
9
Generator ID
0033h = BIOS SMI Handler
11
Sensor Type
13h = Critical Interrupt
12
Sensor Number
05h
13
Event Direction and
Event Type
[7] Event direction
0b = Assertion Event
1b = Deassertion Event
[6:0] Event Type = 71h (OEM Specific)
14
Event Data 1
[7:6] – 10b = OEM code in Event Data 2
[5:4] – 10b = OEM code in Event Data 3
[3:0] – Event Trigger Offset
0h = Receiver Error
1h = Bad DLLP
2h = Bad TLP
3h = Replay Num Rollover
4h = Replay Timer timeout
5h = Advisory Non-fatal
6h = Link BW Changed
7h = Correctable Internal
8h = Header Log Overflow
Fh = Unspecified Non-AER Correctable Error
15
Event Data 2
PCI Bus number
16
Event Data 3
[7:3] – PCI Device number
[2:0] – PCI Function number
