Intelect® Mobile Stim and Combo Therapy Systems
B. Intelect Mobile Stim System
The nomenclature graphics below, Figure 3.2, indicate the general
locations of the exterior components of the Two Channel Intelect
Mobile Electrotherapy System.
Know the components and their functions before performing any
operation of or service to the Intelect Mobile Stim system.
FIGURE 3.2
3 NOMENCLATURE
3.1 COMPONENT AND CONTROLS LOCATION (continued)
FAN VENT
CONTRAST
CONTROL
LCD
USER INTERFACE
PLYNTH
ELECTROTHERAPY
LEAD WIRE
RECEPTACLES
ON/OFF
POWER
SWITCH
