Intelect 2778 - HARDWARE AND SOFTWARE SYMBOL DEFINITIONS

8
Intelect® Mobile Stim and Combo Therapy Systems
The symbols below are found on the system as well as within the
software. These symbols are defined for the purpose of recognition and
functionality when operating or performing service on the Intelect
Mobile Combo or Stim Systems.
Know the symbols and their definitions before performing
any operation of or service to the Intelect Mobile Combo or Stim
Systems.
ON/OFF
SWITCH
DATA
PORT
STOP
TREATMENT
PAUSE
TREATMENT
START
TREATMENT
A. Intelect Mobile Combo and Stim Therapy System Hardware Symbols
CHANNEL 1
LEAD WIRES
CHANNEL 2
LEAD WIRES
ULTRASOUND
APPLICATOR
CLINICAL
RESOURCES
BACK
CONTRAST CONTROL
INCREASE
DECREASE
CHARGE LEVEL
BATTERY
CHARGING
3 NOMENCLATURE
3.2 HARDWARE AND SOFTWARE SYMBOL DEFINITIONS
TREATMENT TIME
INTENSITY
PARAMETER DISPLAY/ENTER
DOWN ARROW
UP ARROW
