Intelect® Mobile Stim and Combo Therapy Systems
A. Intelect Mobile Combo System
The nomenclature graphics below, Figure 3.1, indicate the general
locations of the exterior components of the Two Channel Intelect
Mobile Combo System.
Know the components and their functions before performing any
operation of or service to the Intelect Mobile Combo System.
FIGURE 3.1
3 NOMENCLATURE
3.1 COMPONENT AND CONTROLS
FAN VENT
CONTRAST
CONTROL
LCD
USER INTERFACE
ULTRASOUND
APPLICATOR
PLYNTH
ULTRASOUND
RECEPTACLE
ELECTROTHERAPY
LEAD WIRE
RECEPTACLES
ON/OFF
POWER
SWITCH
