Hardware XI Other connections
Components to buy to
make the cable
Pictures Ref. Farnell Ref. Radiospares
HE10 Connector female
10 pins (quantity 2)
249040 454-2362
Ribbon cable (Quantity
1m or +)
148011 246-8133
Connection to keypad 4 buttons Here is the description of the
connection. Only 5 wires are usefull
to use the 4 buttons of the keypad,
but we advise to connect the 10
wires of the ribbon cable.
Connection to DMX
interface
Page 18
