- 102 -
Motion Detection 1, 2, 3: Click to activate the motion detection window. Once
clicked, you will see a rectangle appear on the
screen. Use the mouse to move the rectangle to a
different position or to resize it.
Threshold: The smaller the number, the lower the threshold of
the amount of movement that triggers an alarm. The
more you increase the threshold value the more
movement is required to trigger an alarm.
Sensitivity: The higher this value, the more sensitive the motion
detection becomes.
Motion is displayed by a green bar (either as shown on top of the detection
window or to the right of the image) and if the detection exceeds the threshold
the color turns red.
Note: Depending on your camera model and firmware version installed, the
screen may have a slightly different layout. Also note that motion detection can
only be set up using MS Internet Explorer as the Web browser.
