131 Eisenhower Lane North
Lombard, IL 60148
630.268.0010 / 1.800.251.2408
P/N 53-00066-400 Rev. B 033004
www.Intellitecsve.com
Intellitec
INSTALLATION MANUAL
BATTERY DISCONNECT
BATTERY DISCONNECT provides a simple and safe means of disconnecting the coach and chassis battery(s) of
an RV. With just the touch of a switch on the monitor panel conveniently located inside the RV, the battery(s) will be
completely disconnected. Since the 12 Volt battery system plays such a vital role in the use and enjoyment of your
RV, Battery Disconnect can give you peace of mind.
Through its correct use you may:
Prevent unwanted discharging of batteries during extended periods of storage
Prevents shorts or fire hazard while storing on the 12 Volt electrical system
Prevent overcharging of batteries if RV is plugged into shore power (120 Vac) for extended periods.
BD0
BD2
BD1
BD3
1
P/N 01-00066-000 P/N 01-00066-001
P/N 01-00066-003P/N 01-00066-002
