6
you have more computers, use LAN2,
LAN3, GbE.
2. Finally, plug the power adapter into an
electrical outlet and contact into the
modem.
3. Start the computer.
4. The colored lights will blink for roughly
30 seconds. If you have connected your
modem properly, the Status and WAN/
DSL lights will be a xed green color.
See picture labeled “Front.” You have
now connected the VG50.
Connecting the
Wireless Local
Area Network (WiFi)
1. Make sure that the WiFi is active,
Wireless LED should be green.
2. For wireless connection rst perform a
search for available wireless networks
using the WiFi client.
3. Compare the list with the NETWORK
NAME (SSID) which is shown on a
sticker on the bottom of the VG50.
4. Connect by double clicking on the
correct NETWORK NAME (SSID) and
then providing the encryption code
which is shown on the sticker labeled
WiFi KEY on the bottom of the VG50.
Description of
the front panel
Graphics on the front panel
1. Status indicator
On (green) – CPE start-up ok
On (red) – CPE start-up problem (con-
tact your operator)
Off – Power off
2. Ethernet indicator
On (green) – LAN connected
Off – LAN not connected
3. WAN indicator
On (green) – WAN connected,
1000 Mps
On (yellow) – WAN connected, 100 Mps
Off – WAN not connected
4. Wireless indicator
On (green) – WiFi activated
Off – WiFi not active
Blinking (green) – active
5. WPS indicator
Blinking (green) – WPS in service
Off – WPS disabled
6. USB indicator
On (green) – USB device connected
Off – USB device not connected
7. DSL indicator
On (green) – connected to the
DSL network
Off – not connected to the DSL network
Blinking (green) – Syncing DSL
Internet indicator
On (green) – Contact with DNS server
Off – No contact with DNS server
Description of
the Buttons
1. WPS
Press the WPS button and the WPS
LED will blink green (max 2 min).
Pair your device and the WPS LED will
be solid green at successful pairing
2. WiFi ON/OFF
Press the WiFi ON/OFF button and
the WiFi will turn OFF or ON
g
h
f
VG50
Multi WAN Wireless Router
