SPECIFICATIONS
M-500 M-700 M-1000
(Front) Power SW: Push up On/Push down Off
Attenuator: 21-position dB calibrated
(Rear) Mode Sw: Bridge=BTL/STEREO/PARALLEL
UL & Canadian Model: 120V, 60Hz
General Model: 230V, 50Hz
British Model: 240V, 50Hz
420W 520W 770W
12kg/26.4lb 15kg/33lb 17kg/37.5lb
482(W) x 88(H) x 369(D) mm/19(W)x3.5(H)x14.5(D)in
Input XLR-3-31 type + 1/4" Phone (balanced), XLR
Output5-Way binding posts x 2, Speakon Terminal x 2
Power Output Level
f=1KHz, THD+N≤0.05% (Typical)
STEREO RL=8Ω
RL=4Ω
BRIDGED RL=8Ω
One Channel Driven
f=1KHz THD+N≤0.05% RL=8Ω
Frequency Response RL=8Ω, P.=1W
Power Bandwidth Half Power, THD+N≤0.1%
STEREO RL=8Ω
Total Harmonic Distortion (THD+N)
f=20Hz~20KHz, Half Power
STEREO RL=8Ω
RL=4Ω
BRIDGED RL=8Ω
Channel Separation Half Power RL=8Ω,
f=1KHz, ATT. max. Input 600Ω shunt
Residual Noise (DIN Audio Filter)
Signal-to-Noise Ratio DIN Audio,
Input 600Ω Shunt
Damping Factor RL=8Ω, f=1KHz
Slew Rate 8Ω Full Swing STEREO
BRIDGED
Sensitivity (ATT max.)
Rated Power into 4Ω 1KHz
Voltage Gain (ATT max.) 4Ω 1KHz
Input Impedance (ATT max.)
Indicators
Protection
PC Limiter
Fan Circuit
Controls
Power Source
Power Consumption
Weight
Dimensions
Connectors
130W+130W 220W+220W 330W+330W
250W+250W 350W+350W 520W+520W
500W 700W 1000W
150W 250W 350W
0dB+0.5, –1.5dB: f=DC~55KHz
10Hz~70KHz
≤ 0.05%
≤ 0.07%
≤ 0.07%
≥ 80dB
≤ –70dB: ATT min.
≥100dB
≥150
±40V/µs
0dBm
32dB 33.5dB 35dB
≥ 20KΩ (Balance/Unbalance)
Power (Red)
Protection (Mute) x 2 (Red)
Clip x 2 (Orange)
Signal x 4 (Green)
Power SW ON/OFF muting
Heatsink Temp ≥ 100˚C (212˚F)
RL < 2Ω
–50˚C (122˚F)–60˚C (140˚F)–
Low-Speed – Variable – Hi-Speed
0dB=0.775 Vrms, Half Power=1/2 Power Output Level (Rated Power)
* Using reactive 2Ω speakers at high power levels may cause overheating, excessive power consumption, and shutdowns.
Please note that below 2Ω the PC limiter will work. Before using 2Ω speakers in a real application, test the system completely.
