PUBLIC ADDRESS MIXING AMPLIFIER
14
PA-206/212/224
Specifications
Specifications
PA-206 PA-212 PA-224
Output Power (1kHz, THD. 1%)
15.5V(4Ω) 31V(8Ω) 31V(4Ω)
70V(82Ω) 70V(41Ω) 70V(21Ω)
100V(167Ω) 100V(84Ω) 100V(42Ω)
S/N
MIC 50dB
RCA, 3.5Φ PHONE JACK
70dB
LINE, TEL IN 70dB
Input Sensitivity /
Impedance
MIC (BALANCE) -70dBu /2k
LINE (BALANCE) -20dBu /2k
RCA (UNBALANCE) -20dBu /2k
3.5Φ PHONE JACK
(UNBALANCE)
-10dBu /10k
TEL IN (BALANCE) -20 ~ 0dBu/10k
EXT IN (BALANCE) 0dBu /20k
MIX OUT (BALANCE) 0dBu /10k
THD+N Rated Power(1kHz) Less than 1%
TONE CONTROL
BASS(100Hz) ±10dB
TREBLE(10kHz) ±10dB
Frequency Response
(1W,±3dB,Low-Z)
LINE
70V 80Hz-17kHz 80Hz-15kHz 80Hz-17kHz
100V 80Hz-17kHz
MIC 100Hz-15kHz
Operating Temperature
-10℃~+40℃
Operating Power AC 220V, 230V, 240V, 50/60Hz
Power consumption (1/8W) 40W 60W 90W
Weight (Set) 6.25kg 7.32kg 9.75kg
Dimensions (Set) 420(W) x 88(H) x 318.7(D)mm
* Design and specification are subject to be changed for the improvement of product quality without pre notice.
